Emerson Appleton Plug and Receptacle, U-Line ECS
Images are representations only.

Appleton™ U-Line™ ECS Factory Sealed 15 & 20 Amp Plugs & Receptacles

Brand: Appleton

Emerson Appleton Plug and Receptacle, U-Line ECS
U-Line™ ECS Factory Sealed 15 and 20 Amp Plugs and Receptacles feature a dead front design making them ideal for use with electrical equipment in hazardous locations. The neoprene gasket in the throat of the receptacle seals against the plug or the spring-loaded cover to seal out water, dust and corrosive compounds. Although U-Line plugs can be used with ordinary receptacles, U-Line receptacles are designed so that they can't be energized by an ordinary plug.
Features
  • Factory sealed, external seals not required. Arcing is safely confined to receptacle interior.
  • Unique blade-type, brass contacts exert constant pressure along entire contact surface and provide superior electrical contact.
  • Energized receptacle contacts deeply recessed to reduce danger of accidental touching.
  • Insulators provide superior dielectric and mechanical strength and lowest arc tracking.
  • ECP plug fits any standard non-explosionproof receptacle (NEMA 5-15R, 5-20R, or 6-20R) as well as U-Line explosionproof receptacles.
  • Intermateable with competitor's plugs of like configurations.

    • Specifications

    Brand

    Amperage

    • 15 or 20

    Hazardous Area Classification

    • Class I, Division 1, & 2 Groups B, C, D, Class II, Division 1, & 2 Group G (Coal Dust), Class III, CSA Typical 7B, C, D, 9 G

    Horsepower Ratings

    • 1, 2

    Materials & Finishes

    • Receptacle, Cover, Mounting Box, Connector Housings, Caps, ECP Plug are Copperfree (4/10 of 1% Max.) Aluminum with Epoxy Powder Coat. Fiberglass Reinforced Polyester Insulating Blocks.

    Mounting Box Entries

    • Dead-End

    Number of Poles

    • 3

    Number of Wires

    • 2

    Plug Cable Diameter

    • .538 - .639

    Voltage

    • 127 Vac or 250 Vac
