Applications
- Aerospace Equipment
- Air Separation
- Cold Service Applications
- FLNG (Floating LNG) Production
- Food Freezing
- High-Purity Gases for Semi-Conductor Applications
- Liquefaction (Export Terminals)
- Liquefied Petroleum Gas (LPG)
- Pharmaceutical (Blanketing, PH Control, Pipe Freezing, Process Chilling, Water Treatment & Shrink Fitting)
- Pipelines & Refueling
- Transport (Trucking, Marine, Rail)
Approvals & Certifications
- API 607 - Fire Tested
- Cryogenic Testing: BSI BS 6364, Bechtel 3PC-PV00-F0001 & Chevron Low-Temperature & Cryo-Service
- FE (Fugitive Emissions) Test: ISO 15848
Ball Material
- 304 Stainless Steel
- 304L Stainless Steel
- 316 Stainless Steel
- 316L Stainless Steel
- 317 Stainless Steel
- 630 Stainless Steel
- Brass
- Inconel®
- Nitronic 50
Enclosure Finish
- Chrome-Carbide Coating
- Electro-Polishing
- Tungsten-Carbide Coating
Enclosure, Body Material
- 304 Stainless Steel
- 304L Stainless Steel
- 316 Stainless Steel
- 316L Stainless Steel
- 317 Stainless Steel
- 630 Stainless Steel
- Brass
- Inconel®
- Nitronic 50
Flange Size - 10" (DN250)
- 10" (DN250) - 150# (ASME)
- 10" (DN250) - 300# (ASME)
- 10" (DN250) - 600# (ASME)
Flange Size - 12" (DN300)
- 12" (DN300) - 150# (ASME)
- 12" (DN300) - 300# (ASME)
- 12" (DN300) - 600# (ASME)
Flange Size - 14" (DN350)
- 14" (DN350) - 150# (ASME)
- 14" (DN350) - 300# (ASME)
- 14" (DN350) - 600# (ASME)
Flange Size - 16" (DN400)
- 16" (DN400) - 150# (ASME)
- 16" (DN400) - 300# (ASME)
- 16" (DN400) - 600# (ASME)
Flange Size - 18" (DN450)
- 18" (DN450) - 150# (ASME)
- 18" (DN450) - 300# (ASME)
- 18" (DN450) - 600# (ASME)
Gasket Material
- Spiral-Wound Body Gasket: Hastelloy® C Grafoil
Handle Assembly Material
- Stainless Steel - Locking Oval Handle, Oval Handle
Operation
- 180° Operation (Diverter Valve)
- 90° Operation (Diverter Valve)
Relief
- Cavity Pressure Relieving Seats
- Self-Relieving
- Upstream End Plate Slot
Seat / Seal Material
- Cryofil
- CTFE
- Graphite
- JLON
- Metal
- PTFE
- Spiral-Wound Body Seal: 316 Stainless Steel
- Spiral-Wound Body Seal: Grafoil
- Spiral-Wound Body Seal: TFE
- Ultrafil
Stem Material
- 304 Stainless Steel
- 304L Stainless Steel
- 316 Stainless Steel
- 316L Stainless Steel
- 317 Stainless Steel
- 630 Stainless Steel
- Brass
- Inconel®
- Nitronic 50 HS
Temperature Range
- -269° to 121° C (-452° to 250° F)
