Ambient Temperature Range
- Operating & Storage: -20° to 40° C (-4° to 104° F) - SE56 Blind
- Operating & Storage: -20° to 60° C (-4° to 140° F) - SE56 Standard with Display
- Operating: -10° to 50° C (14° to 122° F) - SE56 Basic
- Storage: -20° to 50° C (-4° to 122° F) - SE56 Basic
Approvals & Certifications
Communication
- HART - SE56 Standard with Display
- Profibus DP - SE56 Standard with Display & SE56 Blind
- RS-232 - SE56 Standard with Display
- RS-485
Consumption
- Power: 10 W, Maximum
- Power: 25 VA, Maximum
- Power: 6 W, Maximum
Cover Material
- Polyphenylene Sulfide (PPS) - SE56 Blind
Display
- Alphanumeric Display 2 Lines x 16-Characters, without Back Light - SE56 Basic
- Graphic Display 8 Lines x 16-Characters, 128 x 64 Pixels with Back Light - SE56 Standard with Display
Electrical Connectors
- 2 Cable Glands PG9 - SE56 Blind
- 3 Cable Glands PG11 - SE56 Basic
- 6 Cable Glands PG11 - SE56 Standard with Display
Enclosure, Body Material
- 304 Stainless Steel Electro-polish - SE56 Standard with Display
- Die Casting Aluminum - SE56 Standard with Display
- Nylon
- Polyamide 6 (PA6) with Glass Fiber - SE56 Basic
- Stainless Steel - Electronics SE56 Blind
Environmental Protection
- IP65 - SE56 Basic
- IP67 - SE56 Standard with Display & SE56 Blind
Function
- Batch Function - SE56 Standard with Display & SE56 Blind
- Bi-Directional Measure
- Diagnostic Function
- Dual Measurement Range - SE56 Standard with Display
- Empty Pipe Detection
- Plug in (Protected Plug for Connection to PC or Hand Terminal) - SE56 Basic
- Remote Configuration (For Connection to PC or Hand Terminal through Remote Configuration Tool Kit) - SE56 Standard with Display & SE56 Blind
Humidity
- ≤ 85% Relative Humidity, Non-Condensing
Isolation
- Galvanically Isolated (All the Input/Outputs are Galvanically Isolated from Power Supply)
Load Resistance
- 1,000 ohms - SE56 Standard with Display
- 800 ohms Passive - SE56 Blind & SE56 Basic
Output
- 4-20 mA
- Pulse: 100 mA
- Pulse: 40 Vdc
Power Supply
- 12-60 Vdc - SE56 Basic
- 20-30 Vdc - SE56 Blind
- 90-265 Vac - SE56 Standard with Display (44 to 66 Hz) & SE56 Basic
Repeatability
- ± 0.1% of Reading - SE56 Standard with Display & SE56 Blind
- ± 0.2% of Reading - SE56 Basic
Tolerance
- Flow Rate (Volume): ± 0.05% of Reading - SE56 Standard with Display
- Flow Rate (Volume): ± 0.1% of Reading - SE56 Basic
- Output 4-20 mA, Frequency Output: ± 0.08% of Reading - SE56 Standard with Display
- Output 4-20 mA, Frequency Output: ± 0.12% of Reading - SE56 Basic
