WTW Series Heatless Desiccant Air Dryer
Brand: Wilkerson CorporationParker WTW Series Heatless Desiccant Air Dryers remove water vapor from compressed air through a process known as pressure swing adsorption. Pressure dewpoints ranging from -40° F (-40° C) standard to -100° F (-70° C) optional are attained by directing the fl ow of saturated compressed air over a bed of desiccant.
Features- Pre-Filter and After Filters Included with Dryers
- Solid State Controller
- CycleLoc™ Demand Control
- Variable Cyle Control (Models WTW75 - WTW800 SCFM)
- Purge Flow Indicator
- Purge Flow Regulator (Models WTW75 - WTW800 SCFM)
- Repressurization Circuit (Models WTW75 - WTW800 SCFM)
- Control Air Filter (Models WTW75 - WTW800 SCFM)
- Safety Valves
- Pressure Equalization
- 150 PSIG Design Standard
- Moisture Indicator (Models WTW75 - WTW800 SCFM)
Displaying prices & availability for Ohio, United States 43201 in USD. Change location.
Models matching criteria: 13
Capacity 25 CFM @ 100 PSIG (0.7 m3 /min @ 6.9 bar)
Out of Stock
Capacity 42 CFM @ 100 PSIG (1.19 m3 /min @ 6.9 bar)
Out of Stock
Capacity 60 CFM @ 100 PSIG (1.7 m3 /min @ 6.9 bar)
Out of Stock
Capacity 75 CFM @ 100 PSIG (2.13 m3 /min @ 6.9 bar)
Out of Stock
Capacity 107 CFM @ 100 PSIG (3.03 m3 /min @ 6.9 bar)
Out of Stock
Capacity 135 CFM @ 100 PSIG (3.82 m3 /min @ 6.9 bar)
Out of Stock
Capacity 200 CFM @ 100 PSIG (5.66 m3 /min @ 6.9 bar)
Out of Stock
Capacity 250 CFM @ 100 PSIG (7.07 m3 /min @ 6.9 bar)
Out of Stock
Capacity 300 CFM @ 100 PSIG (8.49 m3 /min @ 6.9 bar)
Out of Stock
Capacity 400 CFM @ 100 PSIG (11.32 m3 /min @ 6.9 bar)
Out of Stock
Capacity 500 CFM @ 100 PSIG (14.44 m3 /min @ 6.9 bar)
Out of Stock
Capacity 600 CFM @ 100 PSIG (18.4 m3 /min @ 6.9 bar)
Out of Stock
Capacity 800 CFM @ 100 PSIG (22.65 m3 /min @ 6.9 bar)
Out of Stock
Specifications
Inlet or Ambient Air Temperature
- 120° F (49° C) Maximum
Operating Pressure
- 80 psig (5.5 bar) Minimum
Working Pressure
- 150 psig (10.5 bar) Maximum
Pressure Drop at Rated Flow
- Less Than 5 psi (0.34 bar)
Port Size
- 1/2", 3/4", 1", 1-1/2", 2"
Primary Voltage
- 120 V / 1 ph / 60 Hz
Capacity
- 25 to 800 CFM @ 100 psig (0.7 to 22.65 m3 /min @ 6.9 bar)
