Specifications
Brand
Accuracy
- ± 0.5% of Span (Grade 2A, ASME B40.100)
Ambient Temperature Range
- Dry: -29° to 93° C (-20° to 200° F)
- LF (Glycerin): -7° to 66° C (20° to 150° F)
- PLUS! Performance, Silicone & Halocarbon: -40° to 66° C (-40° to 150° F)
Applications
- Chemical & Petrochemical
- Cryogenic Systems
- Equipment Skids
- Mining & Metals
- OEM Equipment
- Pulp & Paper
- Refineries
- Water & Wastewater Pressure Control
Approvals & Certifications
- CRN
Cover Material
- Back Cover: Polycarbonate
Enclosure, Body Material
- Phenolic
Environmental Protection
- IP54
- IP66
Fill Material
- Glycerin
- Halocarbon
- Silicone
Lens
- Acrylic Lens
- Glass Lens
- Shatterproof Glass
Materials of Construction
- Bourdon Tube & Socket: 316L Stainless Steel
- Bourdon Tube: Brass
- Bourdon Tube: C510 Phosphor Bronze
- Bourdon Tube: Monel® 400
- Bourdon Tube: Monel® 500
- Bourdon Tube: Steel
- Dial: Aluminum, White Background, Black Scale
Mounting
- Flush Mounted
Movement
- 400 Stainless Steel
- Teflon Coated Pinion Gear & Segment
Name Plate, Tag Material
- Stainless Steel
NPT Connection
- 1/2" NPT Male
- 1/4" NPT Male
Pressure Range
- bar: 0 to 2,068
- Feet WC: -34 to 0
- Inches Hg: -30 to 0
- kPa: 0 to 206,800
- psi: 0 to 30,000
Pressure Type
- Compound Pressure
- Gauge
- Vacuum
Process Temperature
- Dry: -29° to 121° C (-20° to 250° F)
- LF (Glycerin): -7° to 93° C (20° to 150° F)
- PLUS! Performance, Silicon & Halocarbon: -40° to 93° C (-40° to 200° F)
Ring Material
- Polycarbonate
Size
- Dial: 4.5"
Storage Temperature
- Dry: -40° to 121° C (-40° to 250° F)
- LF (Glycerin): -18° to 66° C (0° to 150° F)
- PLUS! Performance, Silicone & Halocarbon: -40° to 66° C (-40° to 150° F)
UNF/UNC Connection
- 9/16"-18 UNF Male
